    CAT8 FFTP Shielded LAN Cable 40Gbps 2000MHz LSZH Solid Copper Data Center Cable – Bulk Industrial Network Cable

    Ask Lasest Price
    Brand Name : ITI -LINK
    Model Number : ITI-CTF8-021
    Certification : UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
    Price : $50-$100
    Payment Terms : T/T
    Supply Ability : 2000pcs/day
    Delivery Time : 15-45 Days
    • Product Details
    • Company Profile

    CAT8 FFTP Shielded LAN Cable 40Gbps 2000MHz LSZH Solid Copper Data Center Cable – Bulk Industrial Network Cable

    CAT8 FFTP Shielded LAN Cable 40Gbps 2000MHz LSZH Solid Copper Data Center Cable – Bulk Industrial Network Cable
    Product Overview

    The ITI-LINK ITI-CTF8-021 CAT8 FFTP Cable is a high-performance Shielded LAN Cable engineered for ultra-fast data transmission. Featuring 2000MHz bandwidth and 40Gbps capability, this CAT8 FFTP Cable uses 22AWG Solid Copper conductors and advanced shielding to minimize EMI interference. The LSZH jacket ensures safety in indoor installations, making it ideal for Data Center Cable deployments, Industrial Network Cable systems, and high-density enterprise networks.

    Key Features
    • Professional-grade Shielded LAN Cable for high-speed networking environments
    • Supports 2000MHz bandwidth and 40Gbps transmission
    • 22AWG Solid Copper conductors for lower attenuation and consistent signal transmission
    • FFTP shielding design significantly reduces EMI and crosstalk
    • LSZH jacket improves fire safety and environmental compliance
    • Ideal for data center, industrial automation, and enterprise network applications
    Technical Specifications
    Construction Item DescriptionElectrical Property
    Conductor Material: Bare Solid Copper (elongation: 19-24%)Conductor Resistance at 20°C: ≤ 5.6 Ω / 100m
    Conductor OD: 22 AWGResistance unbalance within a pair: ≤ 0.2%
    Insulation Material: PE Skin-Foam-SkinInsulation Resistance at 20°C: >1500 MΩ / 100m
    Insulation OD: 1.62 ±0.01 mmMutual capacitance: 5600 pF / 100m MAX
    Average THK: 0.50 mmCapacitance unbalance pair to ground: ≤ 160 pF / 100m
    Color Coding: White with colored stripesCharacteristic impedance at 100MHz: 100 ± 15 Ω
    Pair Twist Lay: 19.0-25.0 mmDielectric Strength Test Voltage: 1.00KV DC or 0.7 KV AC for 1 min
    Inner Assemble Lay: S=90 ± 5 mmMechanical Property: Meets industry standards
    Pair Shield Material: Polyester/Aluminium (PET/ALU)Insulation elongation before aging: ≥ 200%
    Pair Shield Coverage: ≥ 200%Insulation tensile strength before aging: ≥10 MPa
    Braid Material: AL-MGJacket elongation before aging: ≥ 125%
    Braid Coverage: ≥ 40%Jacket tensile strength before aging: ≥ 10 MPa
    Jacket Material: LSZH, 60P, -20~75℃Packing: Standard industrial packaging
    Jacket OD: 8.6 ± 0.2 mm
    Jacket Color: Green with black marking
    Applications
    • High-Frequency Trading Networks - Ultra-low latency connections for financial exchanges and trading platforms
    • Data Center Infrastructure - Rack-to-rack connectivity, switch uplinks, and high-bandwidth server clusters
    • AI Computing & GPU Clusters - Stable 40Gbps links for AI training farms and high-performance computing environments
    • Industrial Network Systems - Factory automation, machine control systems, and smart manufacturing
    • 5G Infrastructure - Telecom equipment rooms and 5G base station indoor network cabling
    • Enterprise Backbone Networks - High-capacity network backbones in large commercial buildings
    • Cloud Computing Platforms - High bandwidth for cloud data processing and storage systems
    ITI-LINK CAT8 FFTP Shielded LAN Cable product image
